Strap & Pole Mould Jig Comb Set — CroSoft
The Strap and Pole Mould Jig Comb Set from CroSoft is a premium, industrial-grade tooling
solution designed for precise and efficient assembly of lithium-ion and lead-acid battery packs. Engineered
for heavy-duty production environments, this set includes multiple jigs and comb plates that securely hold
and align battery elements during the moulding, strapping, and pole-fitting processes — ensuring consistent
alignment, reduced rework, and faster assembly cycles.
Key Benefits
- High dimensional accuracy and repeatability for consistent battery assembly.
- Robust construction for long service life in industrial production lines.
- Interchangeable and adjustable jigs to support different battery sizes (IT 500 and similar types).
- Improved operator safety and simplified handling during assembly operations.
- Low maintenance and corrosion-resistant finishes for reliable performance.
Technical & Functional Highlights
The CroSoft jig-comb set is manufactured using high-quality MS alloy components with protective surface
treatments (paint coating and zinc plating) to deliver excellent corrosion resistance in workshop
conditions. Special materials are used for the comb plates to maintain shape fidelity and wear resistance,
even under frequent use. The modular design enables quick replacement of worn parts and flexible production
changes with minimal downtime.
| Application | Battery Grouping / Battery Assembly |
|---|---|
| Body Material | MS (Mild Steel) Alloy |
| Surface Treatment | Paint Coated, Zinc Plated |
| Corrosion Resistance | Yes |
| Type | IT 500 (suitable for NS40–IT500 ranges) |
| Availability | In Stock |
| Brand | CroSoft |
| Main Domestic Market | All India |
Detailed Product Description
One set consists of two robust grouping stands and two precision-machined comb plates which together form
a complete battery grouping assembly. The stands provide a stable base while the comb plates ensure accurate
pole and strap alignment during the assembly and moulding processes. The comb material is specifically selected
for strength and wear resistance so that it maintains performance under continuous production cycles.
The adjustable jigs and modular combs allow manufacturers to quickly adapt to different battery dimensions
— reducing tooling change time and improving line uptime. Whether used in OEM battery lines, replacement battery
production, or R&D prototyping, this set improves overall throughput and assembly quality.
Usage & Advantages
- Quick setup: modular components make assembly and changeover fast and reliable.
- Durability: zinc-plated and paint-coated surfaces for long-term corrosion protection.
- Quality assurance: consistent alignment drastically reduces misassembly and scrap rates.
- Compatibility: suitable for standard battery types including IT 500 and related sizes.
Packaging, Delivery & Support
The product is delivered in export-standard packaging for safe transit. CroSoft offers assembly assistance,
spare-part supply, and technical guidance for integration into your production line. Customization options
(material grade, dimensions, or finish) are available on request to meet specific manufacturing requirements.
Why Choose CroSoft
CroSoft combines engineering expertise with practical manufacturing experience to provide tooling and fixtures
that meet industrial demands. Our focus on quality materials, precision machining, and customer-oriented
customization makes this jig-comb set a reliable choice for high-volume battery producers across India.
For enquiries, customization, or bulk orders — contact CroSoft sales team. Delivering performance, precision, and durability for battery manufacturers.
